5
Technical white paper | HP Z640 Workstation
Intel® USB 3.0
The Intel® C612 PCH has an integrated USB 3.0 controller which provides the four rear, one internal, and four front USB
3.0 ports on the HP Z640 Workstation. The Intel® C612 USB 3.0 controller provides cost-eective support for greater I/O
bandwidth than was provided by the HP Z620 solution. More information on the USB 3.0 Technology and Performance
measurements can be found in the “Resources, contacts, or additional links” section at the end of this document.
USB charging ability
The HP Z640 Workstation equips the top-most of the front USB 3.0 ports with power charging ability. The port is able to
provide fast charge (up to 1.5A) to a portable device in the following states: System On, System Sleep, System Hibernate
and System O. It does not support charging in the ErP (Max S5 Power Savings) state. The port supports USB Battery
Charging Specication 1.2. The port is marked by the battery charging icon shown here. More information on USB
Charging technology can be found in the “Resources, contacts, or additional links” section at the end of this document.
Thunderbolt™ 2
3
technology
The HP Z640 Workstation provides Thunderbolt™ 2 technology via the optional HP Thunderbolt™ 2 PCIe 1-port I/O card.
The HP Thunderbolt™ 2 PCIe 1-port I/O Card uses the Intel DSL5520 Thunderbolt™ 2 controller and provides a single
Thunderbolt™ 2 port.
Each Thunderbolt™ 2 port provides:
• 20 Gb/s data in each direction
• 12 W of power (2 W for cable, 10 W for bus-powered device)
• DisplayPort 1.2 capability with Multi Stream Transport (MST) support that enables the transport of multiple A/V streams
over a single connector
– Maximum 4096 x 2160 resolution at 60 Hz (8-bit display) or at 30 Hz (10-bit display) to a single display
– Maximum 3840 x 2160 resolution at 60 Hz (8-bit display) or at 30 Hz (10-bit display) across 4 displays
• Each of the 4 displays can support a 1920 x 1080 resolution
• 4K video le capture and display simultaneously
• Full backward compatibility with Thunderbolt™ 2 devices.
For more information on Thunderbolt™ 2 technology, benets and installation, please refer to the “Resources, contacts,
or additional links” section at the end of this document.
I/O and storage
Internal I/O
• The HP Z640 provides a total of ve high-performance graphics and I/O slots.
• The HP Z640 provides two PCIe3 x16, one PCIe3 x8, and one PCIe2 x4.
• When in a single processor conguration an additional PCIe2 x1 dedicated electrical slot is available.
• All slots match the mechanical lengths to their electrical lengths and are open ended.
• The HP Z640 also maintains a single PCI slot that is derived from a PCIe to PCI Bridge that brings the total number of I/O
slots to six.
• The HP Z640 provides an internal 1-port USB 3.0 connector and an internal 2-port USB 2.0 header.

HP Z640 Specifications

General

Tcase	72.1 °C
Bus type	QPI
Stepping	R2
Processor cache	20 MB
Processor cores	8
Processor model	E5-2630V3
System bus rate	8 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	16
Processor codename	Haswell
Number of QPI links	2
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1600, 1866 MHz
Memory bandwidth supported by processor (max)	59 GB/s
Maximum internal memory supported by processor	768 GB
Memory slots	4x DIMM
Internal memory	16 GB
Memory clock speed	2133 MHz
Maximum internal memory	- GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Optical drive type	DVD±RW
Card reader integrated	No
Total storage capacity	256 GB
Discrete graphics card	Yes
On-board graphics card	-
Discrete graphics card model	NVIDIA® Quadro® K4200
Discrete graphics card memory	4 GB
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
Chassis type	Tower
Product color	Black
Country of origin	China
Placement supported	Vertical
Product type	Workstation
Motherboard chipset	Intel® C612
Power supply	925 W
HP segment	Business
Operating system installed	Windows 7 Professional
Optional operating system supplied	Windows 8.1 Pro
Scalability	2S
Processor code	SR206
Processor ARK ID	83356
Processor package size	52.5 x 45 mm
Supported instruction sets	AVX
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Depth	464.8 mm
Width	175 mm
Height	444.5 mm
Weight	1500 g
