Technical white paper | HP Z640 Workstation
Storage
The C612 chipset supports two SATA AHCI controllers, sSATA and SATA. The sSATA controller supports four 6 Gb/s ports
and RAID modes 0, 1, 10 and 5. The SATA controller supports two 6 Gb/s ports and RAID modes 0 and 1. Ports from both
controllers can be routed to the rear panel with an eSATA bulkhead option. Note that it is not possible to RAID across the
two SATA controllers.
The optional HP Z Turbo Drive featuring a PCIe connected SSD is supported on this platform and provides performance
levels greater than 1 GB/s. Up to two Z Turbo drives can be congured in the factory. Data RAID is supported through
Microsoft Windows Disk Manager.
External I/O
On the front I/O area, the HP Z640 provides four USB 3.0 ports (the top-most supports battery charging), combo headset
and separate microphone connections.
In the rear I/O area, the HP Z640 provides four USB 3.0 ports, two USB 2.0 ports, one gigabit ethernet LAN port, audio
Line-In, audio Line-Out, and PS/2. Additional rear I/O ports can be added via PCIe add-in cards.
Graphics
The HP Z640 Workstation will support up to a single 300 W graphics card. Separately, in a single processor conguration
the HP Z640 will support up to two cards rated at 225 W each. In a dual processor conguration two cards rated up to 150
W each are supported.
Other features
• 925 W power supply, 90% ecient
• Rear panel power on/o switch and LED for easier rack maintenance
• ENERGY STAR® qualied congurations, China’s Energy Conservation Program (CECP) congurations, European Union’s
ErP LOT6 2013 power limit of 0.5 W in o mode.
• Intel® vPro™
4
manageability with support both for DASH and Intel® AMT (Advanced Manageability Technology) on all
the Xeon® processors. IT managers now have increased exibility in optimizing their Enterprise manageability strategy
across HP’s Commercial Notebooks, Desktops, and Workstations.
HP Z640 vs HP Z620 feature comparison
Table 1. HP Z640 vs HP Z620 feature comparison
HP Z640 HP Z620
Operating System Windows 8.1 Professional 64-bit*
Windows 7 Professional 64-bit*
Windows 8 Professional 64-bit*
Windows 7 Professional 64-bit*
Windows 7 Professional 32-bit*
Processors Intel® Xeon® E5-2600v3
Intel® Xeon® E5-1600v3
Intel® Xeon® E5-2600v2
New instruction set AVX2
AES-NI
AVX
AES
Memory technology DDR4: Registered and LR-DIMMs
Up to 2133 MHz
DDR3: Unbuered ECC and Registered DIMMs
Up to 1866 MHz
USB enhancement USB charging port on top-most front port N/A
USB 3.0 ports 4 Rear, 4 Front, 1 Internal 2 Rear, 2 Front, 0 Internal
Manageability Intel® ME9.1/AMT9.1, Intel® vPro Intel® ME8.1/AMT8.1, Intel® vPro

HP Z640 Specifications

General

Tcase	72.1 °C
Bus type	QPI
Stepping	R2
Processor cache	20 MB
Processor cores	8
Processor model	E5-2630V3
System bus rate	8 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	16
Processor codename	Haswell
Number of QPI links	2
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1600, 1866 MHz
Memory bandwidth supported by processor (max)	59 GB/s
Maximum internal memory supported by processor	768 GB
Memory slots	4x DIMM
Internal memory	16 GB
Memory clock speed	2133 MHz
Maximum internal memory	- GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Optical drive type	DVD±RW
Card reader integrated	No
Total storage capacity	256 GB
Discrete graphics card	Yes
On-board graphics card	-
Discrete graphics card model	NVIDIA® Quadro® K4200
Discrete graphics card memory	4 GB
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
Chassis type	Tower
Product color	Black
Country of origin	China
Placement supported	Vertical
Product type	Workstation
Motherboard chipset	Intel® C612
Power supply	925 W
HP segment	Business
Operating system installed	Windows 7 Professional
Optional operating system supplied	Windows 8.1 Pro
Scalability	2S
Processor code	SR206
Processor ARK ID	83356
Processor package size	52.5 x 45 mm
Supported instruction sets	AVX
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Depth	464.8 mm
Width	175 mm
Height	444.5 mm
Weight	1500 g
