HP ZBook 14u G4

2. Remove the 10 rubber screw covers and the SD card reader blank from the bottom cover.
3. Remove the 10 Phillips M2.5x5.0 screws (1) - (10) and the Phillips M2.0x7.0 screw (11) in the order
shown in the following image.
NOTE: The longer (Phillips M2.0x7.0) screw is located under the SD card reader.
30 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
