14. If it is necessary to replace the WWAN antenna cables, peel the transceivers from the top of the display
enclosure (1), remove the antenna cables from the on the sides of the display enclosure (2), and then
remove the antenna cables (3).
NOTE: The WWAN antennas are spared with the display enclosure.
The display enclosure is available using spare part number 937110-001 for non-IPS panels and
937803-001 for IPS panels.
Reverse this procedure to reassemble and install the display assembly.
70 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
