7 Computer Setup (BIOS), TPM, and HP Sure

Start

Using Computer Setup

Computer Setup, or Basic Input/Output System (BIOS), controls communication between all the input and

output devices on the system (such as disk drives, display, keyboard, mouse, and printer). Computer Setup

includes settings for the types of devices installed, the startup sequence of the computer, and the amount of

system and extended memory.

NOTE: Use extreme care when making changes in Computer Setup. Errors can prevent the computer from

operating properly.

Starting Computer Setup

▲

Turn on or restart the computer, and when the HP logo appears, press f10 to enter Computer Setup.

Using a USB keyboard or USB mouse to start Computer Setup (BIOS)

You can start Computer Setup by using a keyboard or mouse connected to a USB port, but you must rst

disable FastBoot.

1. Turn on or restart the computer, and when the HP logo appears, press f9 to enter the Boot Device

Options menu.

2. Clear the check box for Fast Boot.

3. To save your changes and exit, select the Save icon in the lower-right corner of the screen, and then

follow the on-screen instructions.

– or –

Select Main, select Save Changes and Exit, and then press enter.

Your changes go into eect when the computer restarts.

Navigating and selecting in Computer Setup

●

To select a menu or a menu item, use the tab key and the keyboard arrow keys and then press enter, or

use a pointing device to select the item.

●

To scroll up and down, select the up arrow or the down arrow in the upper-right corner of the screen, or

use the up arrow key or the down arrow key on the keyboard.

●

To close open dialog boxes and return to the main Computer Setup screen, press esc, and then follow

the on-screen instructions.

150 Chapter 7 Computer Setup (BIOS), TPM, and HP Sure Start

Questions and Answers:

Need help?

Do you have a question about the HP ZBook Studio G5 and is the answer not in the manual?

HP ZBook Studio G5 Specifications

General

Form factor	Clamshell
Product type	Mobile workstation
Product color	Gray
Country of origin	China
Market positioning	Performance
LED backlight	Yes
RGB color space	NTSC
Display diagonal	15.6 \
Display brightness	400 cd/m²
Native aspect ratio	16:9
Maximum refresh rate	72 Hz
Bus type	DMI
Processor cache	12 MB
Processor cores	6
Processor model	E-2176M
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Configurable TDP-down	35 W
Processor manufacturer	Intel
Processor boost frequency	4.4 GHz
Configurable TDP-down frequency	2.2 GHz
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model	NVIDIA® Quadro® P1000
On-board graphics card model	Intel UHD Graphics P630
Discrete graphics card memory	4 GB
Discrete graphics memory type	GDDR5
Memory slots	2x SO-DIMM
Internal memory	32 GB
Memory clock speed	2666 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	2 x 16 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	NVMe, PCI Express
Storage media	SSD
SSD form factor	M.2
Total storage capacity	512 GB
Compatible memory cards	SD
Number of SSDs installed	1
Front camera HD type	HD
Antenna type	2x2
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN controller model	Intel Dual Band Wireless-AC 9560
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Pointing device	Clickpad
Operating system architecture	64-bit
HP segment	Business
Battery capacity	95.6 Wh
AC adapter power	150 W
Sustainability certificates	ENERGY STAR
Intel Identity Protection Technology version	1.00
