HP ZR2240w User Manual

3 Setting Up the Monitor
To set up the monitor, ensure that the power is turned off to the monitor, computer system, and other
attached devices, then follow the instructions below.
NOTE: Be sure the master power switch, located on the rear panel of the monitor, is in the off
position. The master power switch turns off all power to the monitor.
Installing the Pedestal
NOTE: Do not install the pedestal if the monitor will be used on a wall, swing arm, or other mounting
fixture; instead see
Mounting the Monitor to User-Supplied Support Hardware on page 15 in this
chapter.
CAUTION: Whenever you handle the monitor, take care not to touch the surface of the LCD panel.
Pressure on the panel may cause non-uniformity of color or disorientation of the liquid crystals. If this
occurs the screen will not recover to its normal condition.
To assemble the ZR2040w, slide the pedestal upright into its base, as shown below.
Figure 3-1 Assembling the ZR2040w pedestal
6 Chapter 3 Setting Up the Monitor ENWW

HP ZR2240w Specifications

General

3D	No
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Response time	8 ms
Display diagonal	21.5 \
Display technology	LED
Contrast ratio (dynamic)	2000000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Digital vertical frequency	50 - 76 Hz
Digital horizontal frequency	24 - 94 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 1600 x 900, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
On/off switch	Yes
USB hub version	2.0
DVI-I ports quantity	0
USB Type-A downstream ports quantity	4
LED indicators	Power
Tilt angle range	-5 - 35 °
Panel mounting interface	No mm
AC input frequency	50 - 60 Hz
Power consumption (max)	52 W
Power consumption (standby)	0.3 W
Power consumption (typical)	35 W
Certification	CSA-NRTL, CSA, FCC. CE, TUV, GOST, NOM, IRAM mark, PSB, VCCI, KC/KCC, Korea E-Standby, ISC, BSMI, \\r C-Tick, CCC, CECP, CEL
Product color	Black
Country of origin	China
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	234 mm
Height (with stand)	367 mm
Weight (with stand)	5740 g
Depth (without stand)	59 mm
Width (without stand)	508 mm
Height (without stand)	303 mm
Weight (without stand)	- g
