HP ZR2240w User Manual

ZR2440w Model
The default input on the ZR2440w is DisplayPort and the scan order is initially set to DisplayPort, DVI-D,
HDMI. You can change the current input, the default and the scan order through the OSD. Pressing the
+ button on the front of the monitor will take you directly to the OSD source-control submenu.
Figure 4-2 ZR2440w Front Panel Controls
Control Function
1
Menu Opens, selects or exits the OSD menu.
2
Minus If the OSD menu is on, press to navigate backward through
the OSD menu and decrease adjustment levels.
3
Plus/source If the OSD menu is on, press to navigate forward through
the OSD menu and increase adjustment levels.
If the OSD menu is inactive, press to activate the source
button that chooses the video signal input (VGA, DVI, or
DisplayPort).
4
OK
OK If the OSD menu is on, press to select the highlighted menu
item.
5
Power Turns the monitor on or off as long as the master power
switch on the rear panel is on.
6 Power LED Blue = Fully powered.
Amber = Sleep mode.
Flashing Amber = Sleep Timer mode.
No light indicates power off, or normal operation if the LED
is suppressed.
ENWW
Overview of Operation
27

HP ZR2240w Specifications

General

3D	No
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Response time	8 ms
Display diagonal	21.5 \
Display technology	LED
Contrast ratio (dynamic)	2000000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Digital vertical frequency	50 - 76 Hz
Digital horizontal frequency	24 - 94 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 1600 x 900, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
On/off switch	Yes
USB hub version	2.0
DVI-I ports quantity	0
USB Type-A downstream ports quantity	4
LED indicators	Power
Tilt angle range	-5 - 35 °
Panel mounting interface	No mm
AC input frequency	50 - 60 Hz
Power consumption (max)	52 W
Power consumption (standby)	0.3 W
Power consumption (typical)	35 W
Certification	CSA-NRTL, CSA, FCC. CE, TUV, GOST, NOM, IRAM mark, PSB, VCCI, KC/KCC, Korea E-Standby, ISC, BSMI, \\r C-Tick, CCC, CECP, CEL
Product color	Black
Country of origin	China
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	234 mm
Height (with stand)	367 mm
Weight (with stand)	5740 g
Depth (without stand)	59 mm
Width (without stand)	508 mm
Height (without stand)	303 mm
Weight (without stand)	- g
