Models ZR2240w, ZR2440w, and ZR2740w use the HP Quick Release 2 mechanism for easy moving
of the monitor. To mount the panel onto the pedestal:
1. Slide the mounting plate on the pedestal under the upper lip of the recess in the back of the panel.
2. Lower the pedestal into the recess until it snaps into place.
3. The HP Quick Release 2 latch pops up when the monitor is locked in place.
Figure 3-2 Mounting the Panel onto the HP Quick Release 2
Rear Components
ZR2040w Model
Figure 3-3 ZR2040w Rear Components
Component Function
1 AC Power Connector Connects the AC power cord to the monitor.
2 Cable Lock Provision Provides slot for use with cable security locks.
3 DisplayPort Connector Connects the DisplayPort cable to the monitor.
ENWW
Rear Components
7

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ZR2240w and is the answer not in the manual?

HP ZR2240w Specifications

General IconGeneral
3DNo
Pixel pitch0.248 x 0.248 mm
Aspect ratio16:9
Response time8 ms
Display diagonal21.5 \
Display technologyLED
Contrast ratio (dynamic)2000000:1
Contrast ratio (typical)1000:1
Display number of colors-
Digital vertical frequency50 - 76 Hz
Digital horizontal frequency24 - 94 kHz
Display brightness (typical)250 cd/m²
Supported graphics resolutions720 x 400, 1600 x 900, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
On/off switchYes
USB hub version2.0
DVI-I ports quantity0
USB Type-A downstream ports quantity4
LED indicatorsPower
Tilt angle range-5 - 35 °
Panel mounting interfaceNo mm
AC input frequency50 - 60 Hz
Power consumption (max)52 W
Power consumption (standby)0.3 W
Power consumption (typical)35 W
CertificationCSA-NRTL, CSA, FCC. CE, TUV, GOST, NOM, IRAM mark, PSB, VCCI, KC/KCC, Korea E-Standby, ISC, BSMI, \\r C-Tick, CCC, CECP, CEL
Product colorBlack
Country of originChina
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Sustainability certificatesEPEAT Gold, ENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)234 mm
Height (with stand)367 mm
Weight (with stand)5740 g
Depth (without stand)59 mm
Width (without stand)508 mm
Height (without stand)303 mm
Weight (without stand)- g
