HP ZR2240w User Manual

Table 4-1 OSD Menu (continued)
Icon Main Menu Submenu Description
Custom Scaling Selects the method on how displayed information on
the monitor will be formatted. Select:
●
Fill to Screen - image fills the entire screen and
may look distorted or elongated because of non-
proportional scaling of height and width
●
Fill to Aspect Ratio - image is sized to fit the
screen and maintains proportional image
●
Fill to 16:9 Aspect Ratio
●
Fill to 4:3 Aspect Ratio
●
Overscan - supports enlarging the image such
that the 5% along each edge disappears outside
the screen. Overscan is available for DVI-D,
HDMI and DisplayPort inputs. This option can be
set to:
◦
Off
◦
On
◦
Auto - scaling is determined by information
that is sent as part of the HDMI input.
Sharpness Adjusts the screen image to look sharper or softer.
Video OverDrive Turns on or off the over drive function that improves
the response time of the panel for watching motion
video. The default is OFF.
Dynamic Contrast Ratio Turning this option on allows the monitor to adjust
Contrast dynamically, as the image changes. The
factory default is Off.
OSD Control Provides a menu for adjusting the on-screen display
(OSD) controls.
Horizontal OSD
Position
Changes the viewing position of the OSD menu to the
left or right area of the screen.
Vertical OSD Position Changes the viewing position of the OSD menu to the
top or bottom area of the screen.
OSD Transparency Adjust to view the background information through
the OSD.
OSD Timeout Sets the time duration in seconds that the OSD is
visible after the last button is pressed. The range is 5 –
60 seconds. The factory default is 30 seconds.
Rotate OSD Rotates the OSD menus and messages to support the
monitor's pivot feature. The choices are Landscape
and Portrait.
Management Selects the OSD and power management features of
the monitor.
ENWW
Overview of Operation
31

HP ZR2240w Specifications

General

3D	No
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Response time	8 ms
Display diagonal	21.5 \
Display technology	LED
Contrast ratio (dynamic)	2000000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Digital vertical frequency	50 - 76 Hz
Digital horizontal frequency	24 - 94 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 1600 x 900, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
On/off switch	Yes
USB hub version	2.0
DVI-I ports quantity	0
USB Type-A downstream ports quantity	4
LED indicators	Power
Tilt angle range	-5 - 35 °
Panel mounting interface	No mm
AC input frequency	50 - 60 Hz
Power consumption (max)	52 W
Power consumption (standby)	0.3 W
Power consumption (typical)	35 W
Certification	CSA-NRTL, CSA, FCC. CE, TUV, GOST, NOM, IRAM mark, PSB, VCCI, KC/KCC, Korea E-Standby, ISC, BSMI, \\r C-Tick, CCC, CECP, CEL
Product color	Black
Country of origin	China
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	234 mm
Height (with stand)	367 mm
Weight (with stand)	5740 g
Depth (without stand)	59 mm
Width (without stand)	508 mm
Height (without stand)	303 mm
Weight (without stand)	- g
