HP ZR30w User Manual

Mounting the Monitor
NOTE: This apparatus is intended to be supported by UL or CSA Listed wall mount bracket.
The HP Quick Release can be removed from the pedestal base and installed to a mounting fixture. It
allows you to quickly and securely attach the monitor panel to the mounting fixture.
1. Remove the monitor panel from the pedestal base. Refer to
Removing the Monitor Pedestal
Base on page 11 in the previous section.
CAUTION: This monitor supports the VESA industry standard 100 mm mounting holes. To attach
a third-party mounting solution to the monitor, four 4 mm, 0.7 pitch, and 10 mm long screws are
required (not provided with the monitor). Longer screws must not be used because they may
damage the monitor. It is important to verify that the manufacturer’s mounting solution is compliant
with the VESA standard and is rated to support the weight of the monitor display panel. For best
performance, it is important to use the power and video cables provided with the monitor.
2. Remove the Quick Release from the pedestal base by removing the four screws.
Figure 3-11 Removing the HP Quick Release from the Pedestal Base
12 Chapter 3 Setting Up the Monitor ENWW

HP ZR30w Specifications

General

3D	No
Pixel pitch	0.2505 x 0.2505 mm
Display surface	Matt
Display diagonal	30 \
Display resolution	2560 x 1600 pixels
Viewable size diagonal	762 mm
Contrast ratio (dynamic)	3000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	370 cd/m²
Supported graphics resolutions	2560 x 1600 (WQXGA)
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
Product color	Black
Country of origin	China
Market positioning	Business
HDCP	Yes
USB hub version	2.0
DVI-D ports quantity	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	5
LED indicators	Power
Tilt angle range	-5 - 35 °
Height adjustment	100 mm
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	2 W
Power consumption (typical)	185 W
Cables included	AC, DisplayPort, DVI, USB
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	276 mm
Height (with stand)	489 mm
Depth (without stand)	87 mm
Width (without stand)	694 mm
Height (without stand)	454 mm
Weight (without stand)	13000 g
