Port Configuration 27
Table 8. Edit Port Configuration Fields
Click Apply to save any changes for the current boot session. The changes take effect immediately
and are applied to each of the selected interfaces. The changes are not retained across a switch reset
unless you click Save Configuration.
Port Summary Statistics
The Port Summary Statistics page displays statistics on packets transmitted and received on each port
or trunk. These statistics can be used to identify potential problems with the switch. The displayed val-
ues are the accumulated totals since the last clear operation.
To display the Port Summary Statistics page, click Switching > Port Configuration in the navigation
pane and select the Statistics tab.
Figure 12. Port Summary Statistics Page
Field Description
Interface The interface or interfaces to be configured.
Admin Mode Select Enabled to make the port accessible on the network, or Disabled to prevent the port
from receiving or forwarding packets.
Physical Mode Select the duplex mode and transmission rate for the selected interface. The options may
differ depending on the port type and include options up to the port's maximum capability.
When Auto Negotiate (the default) is selected, the port negotiates an appropriate link speed
with its link partner.
Port Description Add a description of the interface (optional).
