Overview
The autoloader provides a compact, high-capacity, low-cost solution for simple, unattended data backup. This
unique design houses 8 tape cartridges in its 1U height.
The autoloader is compatible with most operating systems. However, it requires either direct support from the
operating system or a compatible backup application to take advantage of its many features.
To verify compatibility, see the HPE Data Availability, Protection, and Retention Compatibility Matrix at:
http://hpe.com/storage/DAPRcompatibility
Autoloader front panel
1. Power button 2. Mailslot 3. Front panel LEDs
4. Front panel LCD screen 5. Control buttons 6. Air vents
7. Magazine
Autoloader back panel
1. Tape drive assembly 2. Fan
3. Power connector 4. Magazine release hole
5. Pull-out tab containing the serial number and other
product information
6. Ethernet port
7. Serial port (Factory use only) 8. Controller health status indicator
9. USB port
4 Overview
