Shenzhen Hpmont Technology Co., Ltd. Chapter 7 Detailed Function Introduction
HD09 Series User Manual V1.1 -35-
7.7 F06: Multistage Speed Function
Ref. Code Function Description Setting Range [Default]
F06.00 Multiple frequency instruction 1 F00.09 - Max. frequency [5.0Hz]
F06.01
Multiple frequency instruction 2
F00.09 - Max. frequency [5.0Hz]
F06.02 Multiple frequency instruction 3 F00.09 - Max. frequency [5.0Hz]
F06.03
Multiple frequency instruction 4
F00.09 - Max. frequency [5.0Hz]
F06.04 Multiple frequency instruction 5 F00.09 - Max. frequency [5.0Hz]
F06.05
Multiple frequency instruction 6
F00.09 - Max. frequency [5.0Hz]
F06.06 Multiple frequency instruction 7 F00.09 - Max. frequency [5.0Hz]
Define the multistage speed operation mode in the speed of initial value.
7.8 F08: Motor Parameter
Ref. Code Function Description Setting Range [Default]
F08.00 Motor rated power 0.2 - 5.5kW [Type confirmed]
F08.01 Motor rated voltage 0V - Inverter rated voltage
[Type confirmed]
F08.02 Motor rated current 0.01 - 99.99A [Type confirmed]
F08.03
Motor rated frequency
1 - 1000 [50Hz]
F08.04 Motor rated RPM 1 - 24000rpm [Type confirmed]
F08.00 - F08.04 Motor rated parameters need to be in accordance with the motor nameplate.
F08.06 Motor parameters self-tuning 0,1 [0]
0: No action.
1: Motor static self-tuning.
• Motor in static state, the automatic measurement of motor stator resistance, and the measured value
write F08.07 automatically.
• Only under keypad mode (F00.11 = 0), motor parameters self-tuning can be done.
Motor parameters self-tuning setps:
1. Set F08.00 - F08.04 in according to motor nameplate.
2. F08.06 = 1, press , press or to start self-tuning, ”tunE” displayed on keypad.
3. When or indicator flashing, self-tuning is ended, F08.06 recovered to 0 automatically.
F08.07 Motor stator resistance 0.00 - 99.99Ω [Type confirmed]
