Shenzhen Hpmont Technology Co., Ltd. Chapter 10 Parameter
HD09 Series User Manual V1.1 -73-
Ref. Code
Function Setting Range Default Unit
Attribute
Setting
F02: Start and Stop Controlling Parameter
F02.02
Start DWELL frequency
setting
0.0 - F00.08 0.0Hz 0.1Hz
×
F02.03
Retention time of starting
DWELL frequency
0.00 - 10.00s 0.00s 0.01s
×
F02.04 DC braking current setting 0 - 100% 50% 1%
×
F02.05 DC braking time at start 0.00 - 60.00s 0.00s 0.01s
×
F02.13 Stop mode selection
1: Coast to stop
2: Decelerate to stop
2 1
×
F02.14
DWELL frequency setting
at stop
0.0 - F00.08 0.0Hz 0.1Hz
×
F02.15
Retention time of DWELL
frequency at stop
0.00 - 10.00s 0.00s 0.01s
×
F02.16
DC braking initial
frequency at stop
0.0 - 50.0Hz 0.5Hz 0.1Hz
×
F02.18 DC braking time at stop 0.00 - 60.00s 0.00s 0.01s
×
F03: Acceleration and Deceleration Parameter
F03.01 Acceleration time 1 0.01 - 600.00s 10.00s 0.01s
○
F03.02 Deceleration time 1 0.01 - 600.00s 10.00s 0.01s
○
F03.03 Acceleration time 2 0.01 - 600.00s 10.00s 0.01s
○
F03.04 Deceleration time 2 0.01 - 600.00s 10.00s 0.01s
○
F03.05 Acceleration time 3 0.01 - 600.00s 10.00s 0.01s
○
F03.06 Deceleration time 3 0.01 - 600.00s 10.00s 0.01s
○
F03.07 Acceleration time 4 0.01 - 600.00s 10.00s 0.01s
○
F03.08 Deceleration time 4 0.01 - 600.00s 10.00s 0.01s
○
F03.09
Ace. time 2 and 1 switch
frequency
0.0 - up limitation 0.0Hz 0.0Hz
×
F03.10
Dec. time 2 and 1 switch
frequency
0.0 - up limitation 0.0Hz 0.0Hz
×
F03.15 Spot Ace. time 0.01 - 600.00s 6.00s 0.01s
○
F03.16 Spot Dec. time 0.01 - 600.00s 6.00s 0.01s
○
F04: Process PID Controlling Parameter
F04.00
Process PID control
selection
0: PID control is disabled
1: PID control is enabled
0 1
×
F04.02 Feedback source selection
0: AI analogue feedback
1: Terminal pulse feedback
0 1
×
