Shenzhen Hpmont Technology Co., Ltd. Chapter 5 Technical Data
HD09 Series User Manual V1.1 -21-
5.3 Technical Data
Electrical
Inout voltage
HD09-2S
P
G: Single-phase 200 - 240V
HD09-4T
P
G: Three-phase 380 - 460V
Fluctuating within ±10%, imbalance rate < 3%
Input frequency 50/60Hz ± 5%
Output voltage 0 - input voltage
Output frequency 0 - 1000Hz
Specification
Control mode V/f
Maximum current 150% rated output current 2 minutes; 180% rated output current 10 seconds
Speed resolution
Digital setting: 0.1Hz;
Analogue setting: 0.1% × maximum frequency
Wave frequency
Default setting: 4kHz; Setting range: 1 - 16kHz;
4 - 16kHz: The derating value of wave frequency shall be 2% for each more than 1kHz
Environment
Operation
temperature
-10 - +40°C, no ferating;
40 - 50°C, the derating value of the output current shall be 2% for each more than 1°C
Storage temperature -40 - +70°C
Location for use
Indoor, preveting from direct sunlight, no dust, corrosive, flammable gases, oil mist, water
vaper, dripping or salt etc.
Altitude Less than 1000m, no ferating; Otherwise shouldbe serating use
Humidity Less than 95%RH, non-condensing
Vibration Resistance It is 3.5m/s
2
in 2 - 9Hz, it is 10m/s
2
(IEC60721-3-3) in 9 - 200Hz
Protection level IP20
Pollution degree Level 2 (Dry, Non conducting dust pollution)
Accessories
Keypad
HD-LED-P: LED keypad with potentiometer, matched with HD-KMB mounting base
HD-LED-P-S: Small size keypad, matched with HD-KMB-S mounting base
Connection cable 1m / 2m / 3m / 6m connection cable [HD-CAB-1M / 2M / 3M / 6M]
