hpmont HD30 Series Simple Manual

Ref.
Code
Function
Register
Address
Remark
Status Display Parameters
D00.08 Inverter rated current (A) 0x3308
D00.14 Setting frequency (Hz) 0x330E
D00.15 Given frequency (Hz) 0x330F
D00.16 Output frequency (Hz) 0x3310
D00.17 Setting speed (rpm) 0x3311
D00.18 Running speed (rpm) 0x3312
D00.20 Output voltage (V) 0x3314
D00.21 Output current (A) 0x3315
D00.22 Torque reference (%) 0x3316
D00.23 Output torque (%) 0x3317
D00.24 Output power (kW) 0x3318
D00.25 DC bus voltage (V) 0x3319
D00.27 AI1 input voltage (V) 0x331B HD09/HD09-S is AI
D00.29 AI2 input voltage (V) 0x331D
D00.31 AI3 input voltage (V) 0x331F
D00.35
DI6 terminal pulse input frequency
(Hz)
0x3323
HD07-S is DI5
HD09/HD09-S is DI4
D00.36 AO1 output 0x3324
HD07-S/HD09/
HD09-S is AO
D00.37 AO2 output 0x3325
D00.38
DO2 high-speed output pulse
frequency (Hz)
0x3326 HD09/HD09-S is DO
D00.39 Radiator temperature (℃ ) 0x3327 HD07-S none
D00.50 Input terminal status 0x3332
D00.51 Output terminal status 0x3333
Ref.
Code
Function Setting Range Default Remark
Basic Parameters
F00.01
Motor control mode
selection
0: V/f control without PG
2: Vector control without PG
5: PM with PG vector control
0
Only
HD50
has 5
F00.06
Max. output
frequency of inverter
50.00 - 400.00Hz 50.00Hz
F00.08
Max. running
frequency
0.00Hz - F00.06 50.00Hz
F00.09
Min. running
frequency
0.00Hz - F00.08 0.00Hz
F00.10
Frequency setting
channel selection
0: Keypad setting
1: Terminal setting
2: SCI communication
setting
3: Analog setting
4: Terminal pulse setting
6 - 9: AI1 - AI4 setting
10: Keypad potentiometer
setting
0
HD09/
HD20
don
,
t
have
6 - 10
F00.11
Command setting
channel selection
0: Keypad setting
1: Terminal setting
2: SCI communication
setting
0
F00.13
Starting frequency
digital setting
0.00Hz - Max. frequency 50.00Hz
F00.15
Jog operation
frequency
digital setting 1
0.00Hz - Max. frequency 5.00Hz
F00.17
Running direction
selection
0: Same direction
1: Reverse direction
0
F01.00 User password 00000 - 65535 0
F01.02
Function code
parameter
initialization
(parameter
download)
0: No operation
1: Restore factory
parameters
2/3: The keypad storage
parameter 1/2 is copied to
control board and update
the current parameter
setting value
4: Clear the fault
0
Function Parameters
Instruction:
For the description of each product terminal, see control terminal (electrical
installation) or remarks (function parameter).
