Page #7 background image
Ref.
Code
Function Setting Range Default Remark
F01.03
Parameter copy to
keypad (parameter
upload)
0: No operation
1/2: The current parameter
setting value is copied
to the keypad storage
parameter 1/2
0
F03.01 Acc. time 1 0.1 - 6000.0s Depend
on
modelF03.02 Dec. time 1 0.1 - 6000.0s
F06.00 -
F06.07
Multi-segment
frequency command
1 - 8
F00.09 - Max. frequency 5.00Hz
PID Parameter
F04.00 PID control selection
0: Invalid
1: Valid
0
F04.01
Given channel
selection
0: Digital given
1: Analog given
2: Terminal pulse given
3 - 6: AI1 - AI4 given
7: Keypad potentiometer
given
0
HD07-S
doesn
,
t
have
3 - 7
F04.02
Feedback channel
selection
0: Analog feedback
1: Terminal pulse feedback
2 - 5: AI1 - AI4 given
6: Keypad potentiometer
given
7: Speed closed-loop
feedback
0
HD07-S
doesn
,
t
have
2 - 7
F04.03
Quantitative digital
setting
-100.0 - +100.0% 0.0%
F04.04
Proportional gain
(P1)
0.0 - 500.0 50.0
F04.05 Integration time (I1) 0.01 - 10.00s 1.00s
F04.07 Derivative time (D1) 0.00 - 10.00s 0.00s
Motor and Encoder Parameters
F08.00 Motor rated power 0.2 - 999.9kW
Depend
on
model
F08.01 Motor rated voltage 0 - 999V
F08.02 Motor rated current
5.5kW and below:
0.01 - 250.00A
About 5.5kW: 0.1 - 2500.0A
F08.03
Motor rated
frequency
1.0 - 400.0Hz 50.0Hz
F08.04 Motor rated RPM 1 - 24000rpm
Depend
on
model
F08.06
Motor parameter
auto-tuning
0: No action
1: Static auto-tuning
2: Rotation auto-tuning
0
HD09
doesn
,
t
have 2
F09.00
Motor V/f curve
setting
0: Straight line
1: Square curve
0
HD09
none
F09.07 Motor torque boost
0.0 - 30.0%
0.0: Auto torque boost
Depend
on
model
F14.00
Encoder feedback
signal type
0: Invalid
1: ABZ signal
2: UVW signal
3: SINCOS signal
0
Only
HD50
hasF14.01
Encoder pulses per
revolution
1 - 9999 1024
F14.02
Encoder rotation
direction setting
0: Same direction
1: Reverse direction
0
Function Parameters
