hpmont HD30 Series Simple Manual

Ref.
Code
Function Setting Range Default Remark
Digital and Analog I/O Terminal Parameters
F15.00 DI1 terminal function
0: Unused
1: Inverter is enabled
2, 3: FWD/REV function
13 - 16: Multi-segment
frequency terminal 1 - 4
20, 21: FWD/REV Jog 1
command control input
(JOGF1/JOGR1)
43: Emergency stop
46: External reset (RST)
input
53: Pulse frequency input
(HD07-S is DI5, HD09/
HD09-S is DI4, the rest is
DI6）
2
F15.01 DI2 terminal function 3
F15.02 -
F15.05
DI3 - DI6 terminal
function
0
F15.14
Terminal detection
filtering times
0 - 10000 2
F15.15
Terminal input
positive and negative
logic setting
Bit0 - Bit8 corresponds to
DI1 - DI9
Bitx: DIy terminal input
positive and negative logic
0: Positive logic
1: Negative logic
000
F15.18
DO1 terminal
function
0: Unused
2: Inverter running (RUN)
9: Frequency level detection
signal
11: Frequency arrival signal
(FAR)
31: Inverter fault
38: High-speed pulse
output (HD09/HD09-S is DO,
the rest is DO2）
2
HD09/
HD09-S
is DO
F15.19
DO2 terminal
function
0
F15.20 RLY1 relay function 31
F15.27 FAR detection width 0.00 - 100.00Hz 2.50Hz
F15.30 FDT1 detection mode
0: Detect according to the
reference frequency
1: Detect according to the
output frequency
0
HD07-S
none
F15.31 FDT1 level 0.00Hz - Max. frequency 50.00Hz
F15.32 FDT1 lag 0.00Hz - Max. frequency 1.00Hz
F16.00
Keypad
potentiometer
function
0: Unused
2: Frequency setting
4: Process PID given
5: Process PID feedback
0
F16.01 AI1 terminal function 2
HD09/
HD09-S
is AI
F16.02 AI2 terminal function 5
F16.03 AI3 terminal function 0
F16.17
Max. input pulse
frequency
0 - 50000Hz 10000Hz
HD07-S
is DI5
HD09/
HD09-S
is DI4
F16.19
AO1 terminal
function
0: Unused
1: Output frequency (0 -
Max. output frequency)
2: Given frequency (0 - Max.
output frequency)
3: Motor RPM (0 - Max.
output frequency)
4: Output current (0 - twice
motor’s rated current)
2
HD07-S/
HD09/
HD09-S
is AO
F16.20
AO2 terminal
function
0
F16.21
High-speed pulse
output function
0
F16.26
DO2 Max. output
pulse frequency
0.1 - 50.0kHz 10.0kHz
HD09/
HD09-S
is DO
F16.29
AI1 voltage current
input selection
0: Voltage input
1: Current input
0
Only
HD07-S
Function Parameters
