MPT-II User Manual
www.hprt.com
10
Chapter 2 Specifications
2.1 Printing specifications
1) Printing method: Line thermal
2) Paper width: 56mm
3)
Paper thickness: 60 ～80μm
4) Valid printing width: 48 mm
5) Resolution: 8 dot/mm (230 dpi)
6) Dot /line: 384 dots
7) Printing speed: 50-80 mm/s
8) Printing content:GB18030 character set, ASCII characters, user defined
characters, bar codes CODE39, EAN13, EAN8, CODABAR, CODE93, ITF, bitmaps.
2.2 Physical specifications
1) Outer dimension: 92.5 x 75 x38mm
2) Weight: 205g(excluding paper roll)
3)
Paper Diameter:30mm
4) Interface: Original IR( RAW_IR), VIR, IrDA ( IrCOMM), RS232 serial, Bluetooth
Interfaces varied with different models.
2.3 Environment specifications
1) Operation temperature: -10～50～
2)
Operation humidity: 20% ～85%
～
3)
Storage temperature : -20～～70
～
4)
Storage humidity: 5% ～95%
～
2.4 Other specifications
1) Paper loading method: drop-in easy loading
2) Black mark detection: available (details please see 4.2 preprinting black mark
specification).
3) Paper out detection: when paper is out, the Mode indicator blinks, and the buzzer
rings twice.
4) Print commands: ESC/POS compatible command set.
5) Power supply: 1500mAh rechargeable polymer lithium battery.
6) Low power alarm: when the battery is low, the power indicator blinks and the
buzzer rings 2 times; and if the user doesn’t charge, it will intervaly beep to inform
the user to charge.
