TP80K User Manual
21
4.3 Cash Drawer Connection
1) Make sure the printer's power switch is turned off;
2) Connect the cash drawer cable into the cash drawer interface on the rear side of the printer.
Warning:
Cash drawer interface can only be connected to a voltage of 24V cash drawer device (can’t
connect to the phone line, etc.)
4.4 LED Indicator and Beeper
Function specification of indicated light and beeper.
LED Name
LED Status
Printer Status
POWER
LED
（Blue）
ON
The printer works well.
OFF
The printer is power off.
ERROR
LED
（Red）
Flash
The printer is in error status.
OFF
The printer is in normal status.
PAPER
LED
（Orange）
ON
The printer is in paper end status.
/ The printer cover is open.
OFF
The printer is in normal status.
Note: The printer uses a thermistor to detect the temperature of the print head. If the
temperature of print head is higher than 65° C, printer will send a warning. If the temperature
of print head is higher than 80° C, printer will stop working until the temperature is lower
than 60° C.
Error Description
POWER
LED
ERROR
LED
PAPER
LED
Beeper
cover opening
ON
ON
ON
“Beep ,Beep--,Beep”
Paper End
ON
ON
ON
“Beep, Beep, Beep”
Cutter Jam
ON
Flash
OFF
”Beep—, Beep—”
TPH
over-temperature
ON
Flash
OFF
“Beep ,Beep--,Beep”
Over-voltage
/ Low-voltage
ON
Flash
OFF
“Beep, Beep, Beep”
