HPtec SD4030B3 User Manual

7
7.Setting of switch SW 1
■ Setting of JOG operation
5
6
JOG rotation
☆
ON
ON
CW
ON
OFF
CCW
OFF
OFF
JOG disable
Caution) In case of pulse input operation,
be sure to set 5 and 6 to OFF.
■ Setting of Auto Current Down
4
☆
ON
Enable
OFF
Disable
■ Setting of Division Number
1
2
3
Division
number
ON
ON
ON
1/2
ON
ON
OFF
1/8
ON
OFF
ON
1/10
ON
OFF
OFF
1/16
OFF
ON
ON
1/20
OFF
ON
OFF
1/32
OFF
OFF
ON
1/40
OFF
OFF
OFF
1/64
☆
ON
