HSD ES929 - Page 38

HSD
5801H0056 _______________________________________________________________ 38/181
H1423H0204 Rev.01 (SP.110.130.48)
Rated voltage (*) V
380 380 380 380 380 380 380 380
Rated frequency Hz
400 500 600 667 733 800 867 933
Rated speed rpm
12,000 15,000 18,000 20,000 22000 24,000 26000 28,000
Duty type
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
Rated power kW
12 14 9.5 12 8.2 10 7.3 8.8 6.4 7.5 5.5 6.2 4.6 4.9 3.5 3.6
Rated torque Nm
9.5 11.1 6 7.6 4.6 5.3 3.5 4.2 2.8 3.3 2.2 2.5 1.7 1.8 1.2 1.2
Rated current A
27.5 32 22 26.4 16.5 20 17 20.5 16.5 19 14 15.7 11.8 12.5 8.9 9.2
Rated output η
0.86
Power factor cos ϕ
0.8
Number of poles
4
Type of insulation
F
Type of cooling
Raffreddamento a liquido / Flüssigkeit / Liquid cooling
Weight of
SHORT NOSE version
kg
30
Weight of
LONG NOSE version
kg
34
[(*) supplied by
inverter]
