MULTITEST M72 - M73 - M74 - M75
EN - 40
6. TECHNICAL SPECIFICATIONS
This product conforms to the prescriptions of the European directive on low voltage
73/23/EEC (LVD) and to EMC directive 89/336/EEC, amended by 93/68/EEC.
6.1. CHARACTERISTICS
Accuracy is indicated as [% of reading + digit number]. It is referred to the following
reference conditions: 23°C ± 5°C with RH <70%.
DC and AC TRMS voltage measurement
Range Resolution
Accuracy
DC
Accuracy
(30 ÷ 70Hz)
Accuracy
(70 ÷ 400Hz)
Input
impedance
1.0 ÷ 999.9mV
0.1mV
1.000 ÷ 9.999V
0.001V
10.00 ÷ 99.99V
0.01V
100.0 ÷ 605.0V
0.1V
±(0.5% rdg +
2 dgt)
±(1.0% rdg +
2 dgt)
±(2.0% rdg +
2 dgt)
1MΩ
MAX, MIN, AVG, PEAK, resolution: ±(5.0% rdg + 10 dgt); responce time: 500ms (MAX, MIN, AVG),1ms (PEAK)
Max crest factor: 3.0: V<1.0V; 1.5: V≥1.0V
DC and AC TRMS current measurement (with external jaws)
Range Resolution
Accuracy
DC
Accuracy
(30 ÷ 70Hz)
Accuracy
(70 ÷ 400Hz)
Input
impedance
Overload
protection
1.0 ÷ 999.9mV
0.1mV
1.000 ÷ 1.200V
0.001V
±(0.5% rdg
+ 2 dgt)
±(1.0% rdg +
2 dgt)
±(2.0% rdg +
2 dgt)
1MΩ
605V AC
max RMS
The mentioned accuracy does not consider the transducer's accuracy. Please refer to its user's manual
MAX, MIN, AVG, PEAK, resolution: ±(5.0% rdg + 10 dgt); responce time: 500ms (MAX, MIN, AVG),1ms (PEAK)
Minimum input current: 1mV x transduction ratio of the clamp
Max crest factor: 3.0: V<1.0V; 1.5: V≥1.0V
Frequency measurement with test leads
Range Resolution Accuracy Input impedance
30.0 ÷ 199.9Hz
0.1Hz
200 ÷ 400Hz
1Hz
±(0.5% rdg + 2 dgt) 1MΩ
Input voltage: 1mV ÷ 605.0V
Frequency measurement with jaws
Range Resolution Accuracy Overload protection
30.0 ÷ 199.9Hz
0.1Hz
200 ÷ 400Hz
1Hz
±(0.5% rdg + 2 dgt)
605V AC max RMS
Input voltage: 1mV ÷ 1V
Resistance and continuity test
Range Resolution Accuracy Overload protection
0.00 ÷ 39.99 Ω 0.01Ω
40.0 ÷ 399.9 Ω 0.1Ω
400 ÷ 3999 Ω 1Ω
4.00 ÷ 39.99 kΩ 10Ω
±(1.0% rdg + 5 dgt)
605V AC max RMS for 1 minute
The buzzer sounds while measured resistance is lower than 40Ω
