HT MULTITEST M72 User Manual

MULTITEST M72 - M73 - M74 - M75
EN - 6
4. OPERATING INSTRUCTIONS
4.1. INSTRUMENT - DESCRIPTION
LEGEND:
1. Inputs
2. Display
3. ON/OFF key
4. MODE PEAK key
5. Arrows key
6. FUNC HOLD key
7. GO key
8. Remote units for LAN tests
(M75 only)
Fig. 1: Instrument description
to switch on/off the instrument
MODE
PEAK
MODE key to select working mode
PEAK key to select peak measurement
FUNC
HOLD
FUNC key to select working mode
HOLD key to stop display updating
GO
to start a measurement
Arrow keys to select measurements
