51H40485-XXM PCBA-MAIN BOARD (Side B)
Location P/N Description Remark
MAM14 75H00628-00M Connector FPC,45P,100mohm,HIROSE,FH26-45S-0.3SHW(05),0.2A,30V,0.3SHW
Upper board
FPC
MAM8 75H00771-00M Connector I/O,40mohm,ACON,C-MJE23-00-00,11P,0.45Pitch,0.5A,30V
USB
Connector
PACON1 75H00776-00M Connector Device,60mohm,SUYIN,060062MB003GX01ZL,3P,2.75Pitch,2A,12V
Battery
Connector
