10. RF Antenna Specification
EIRP & Sensitivity Test
Channel 975 42 124
EIRP (dBm)
EIRP Spec
28.0 28.0 28.0
Cell power (dBm)
EGSM
Cell power Spec (dBm)
-104 -104 -104
Channel 512 698 885
EIRP (dBm)
EIRP Spec
28 28 28
Cell power (dBm)
DCS
Cell power Spec (dBm)
-104.0 -104.0 104.0
Channel 512 661 810
EIRP (dBm)
EIRP Spec
26 26 26
Cell power (dBm)
PCS
Cell power Spec (dBm)
-104.0 -104.0 104.0
Channel
2937 3013 3088
EIRP (dBm)
EIRP Spec
18 18 18
Cell power (dBm)
WCDMA Band VIII
Cell power Spec (dBm)
-104.0 -104.0 104.0
Channel
10563 10700 10837
EIRP (dBm)
EIRP Spec
18 18 18
Cell power (dBm)
WCDMA Band I
Cell power Spec (dBm)
-104.0 -104.0 104.0
