6.3 Main unit inspection
Gap & Step inspection
Description Accept criteria Level
1 GAP BETWEEN ALL GENERIC ME PARTS < 0.4 mm Minor
2 GAP BETWEEN TOUCH WINDOW AND A PARTS < 0.3 mm Minor
3 STEP BETWEEN MATING PARTS < 0.3 mm Minor
It is generic cosmetic inspection criteria for all products if there have any conflict with these generic criterions; please
follow the product inspection criteria respectively.
