Doc. Title
Diamond Service Manual
Page 96 of 109
HTC CONFIDENTIAL
SM-TP001-0704
HTC Corporation
9. Generic Spare Part List and Photos
9.1 SPL for Repair
Item P/N Description Qty Substitute
1
35H00112-00M
BATTERY_LI-ION,900mAh,3.7V,TWS,ICP533640SR,MAXELL,60/-20degC,42*40
*5.5mm
1
2 36H00684-00M Speaker,KDIC,MPS-101706BA 1
3
36H00685-00M Receiver,KDIC,MPR061501DA 1
5 51H10073-00M Rigid-Flex Board ASSY, Upper BD with ACF Assy, Diamond 1
6
54H00278-00M
Camera Module,FF,Largan,Largan,PREMIER,NBR727 Module drawing, mutual
tek,0.3Mpixel,5*5*2.62mm,Diamond
1
7
54H00279-00M
Camera Module,PREMIER,CMHT-3A403D,AF,TDK,LARGAN,相互,Micron
MI-3130,3.1Mpixel,Micron,19.2*8.9*6.3mm,Raphael
1
8 71H02327-00M Cover, MEGA POWER,COVER LEFT COAXIAL CABLE,DIAMOND 1
9 71H02328-00M Button, UNITEL, PWRBTN, DIAMOND 1
10 71H02329-00M Button, UNITEL, VOLBTN, DIAMOND 1
11 72H02445-00M Magnet, MAGNET DIAMOND 1
12 72H02453-00M Screw,FPHM1.2-1.1(2.6,0.3),Diamond 2
13 72H02454-00M Screw,FPHM1.2-0.25*2.4(2,0.35),AISI-1018,BLACK,Diamond 2
14 72H02456-00M Screw,FPHM1.4-0.3x2.0(2.55,0.2)Ni/BI, Diamond 4
15 72H02460-00M Cover, JUN-YEN, metal cover label, Diamond 1
16 72H02474-00M Screw,M1.4-L4.3-D2.6 4
17 72H02767-00M Screw,M1.4-L4.3-D2.6,Silver,Diamond 2
18 73H00278-00M Cable,MURATA,MXHP34HP0590,PLUG CABLE, coaxial cable, GPS,DIAMOND 1
19 73H00280-00M Cable,MURATA,MXHP34HP0980C1,coaxial cable, BT/WiFi, DIAMOND 1
20 73H20139-41M FPC Pre-Assy, SIM, GLOBAL FLEX, Diamond 1
21 74H01123-00M Sound Box Pre-Assy,DIAMOND 1
22 74H01131-00M Cover Pre-Assy,Antenna,Diamond-A,Diamond 1
23 74H01132-00M Cover Pre-Assy,Battery,Diamond-A,Diamond 1
24 74H01133-00M Cover Pre-Assy,SIM,Diamond-A,Diamond 1
25 74H01139-00M Support Pre-Assy, ASSY Support cover right, RF cable, Diamond 1
26 74H01144-00M Keycap Pre-Assy,htc navi,diamond 1
27 74H01159-00M Stylus Pre-Assy,Diamond-A,Diamond 1
28 76H02515-00M Rubber,Silicon,MIC,Diamond 1
29 76H02650-00M Cushion,speaker,27.9*12.75*0.5mm,SCF100,Diamond 1
30 76H02653-00M Tape,BTB connector,16*10*0.06mm,Kapton,Diamond 1
31 76H02656-00M Rubber,BT coaxial plug holder,Diamond 1
32 76H02692-00M Mylar,upper board switch,6.5*4.5*0.05mm,Diamond 1
33 76H02756-00M Mylar,Power key,Diamond 1
34 77H00460-00M Tamper-Evident Label, VOID wording, black background,3*3mm,MING JYE 1
35 77H00598-00M Regulation Label,40.3*38.55mm,CHENG MAY,DIAM300,Diamond 1
36 77H02203-00M Water Sensitive Label,4*2.5mm,Ming Jye, BlueAngels 1
37
80H00704-00
FRU-SUB ASSY,TFT-LCD MODULE,TPK,TPK_TW,HITACHI,Black,W/
Bezel,Diamond
1
38 99HEJXXX-02 PCBA Main Board and sub board 1
