4. DIAGNOSTIC PROGRAM
4.1 List of Diagnostic / WinCE Test Items
Mode No Item Description Remark
Function Test
1 Auto Auto Regular Tests (Display, B.L, Vibrator, etc…)
2 ROM Checksum Test ROM size
3 Stylus Detect Test Stylus remove and insert
4 LED Test Backlight of Navi board module
5 Display Test Color bar/R/G/B/Black/White/Gray pattern.
6 LCD Back Light Test LCD back light test (On/Dim/Off).
7 Vibrator Test Vibrator on test.
8 Key Test
Power, Volume up, Volume down, Key
action, Key left, Key up, Key right, Key down
9
G Sensor Test Motion G sensor function test
Run-in Test
1 1 Hour 1 Hour Run-in Test/Press Soft1 key. Option
2 2 Hours 2 Hours Run-in Test/Press Soft 2 key. Option
3 4 Hours 4 Hours Run-in Test/Press Start key. Option
4 8 Hours 8 Hours Run-in Test/Press OK key. Option
Format Internal Storage (Personal information, talk times)
Diagnostic
Device Info
1 Bluetooth Test Bluetooth Function Test
2 USB Test USB link test (Microsoft ActiveSync)
3 Camera Test Camera Function Test
4 WLAN Test WLAN Function Test
5 GPS Test GPS Function Test
6 FM Radio FM Radio Function Test
7 Audio Test
All Audio Function Test
Win CE
8 Cap Sensor Test
Navi Cap Sensor Function Test
