RUU-1
7. Hold the volume down key then
press power button to trigger the
boot loader mode.
8. Read the pop-up message form
ROM update utility and select the “I
understand…” checkbox.
9. Click “Next” to proceed.
RUU-2
10. Read the pop-up message form
ROM update utility to follow and
perform the instructions and select
the “I completed…” checkbox.
11. Click “Next” to proceed.
RUU – 3
12. Current image version
confirmation.
13. Click “Update” to proceed
