25
Diagrama elétrico
※ Se mudar, nenhum conselho especial!
Entrada de
energia
120 VAC/220
VAC
, 50Hz/60Hz
Termostato
DC Fan
Válvula
de gás
Válvula Sepa-
rada de Gás_1
Válvula Sepa-
rada de Gás_2
Válvula de
gás principal
Sensor de fluxo de água
Dispositivo
de ignição
Sensor de temperatura de saída de água
Sensor de temperatura de entrada de água
Detecção de chamas
GND
Display
