25
Electrical diagram
※If change, No special advice!
Power Input
120 VAC/220 VAC
,
50Hz/60Hz
Thermostat
DC Fan
Gas
Valve
Gas Separate
Valve_1
Gas Separate
Valve_2
Main Gas
Valve
Water Flux Sensor
Igniter
Water Outlet Temperature Sensor
Water Inlet Temperature Sensor
Flame detect
GND
Display
