Supplied Parts and Hardware
X1
MAX:100
mm/4 in.
MAX:100
mm/4 in.
100 mm ≈ 4 in.
75 mm ≈ 3 in.
01
X1
02
X1
03
X1
04
X1
05
IMPORTANT SAFTY INSTRUCTIONS
Check the VESA Pattern of Monitor Before the Installation
Please carefully read all instructions before attempting installation. If you do
not understand the instructions or have any concerns or questions, please
contact our customer service at support@huanuoav.com
CAUTION: Avoid potential personal injuries and property damage!
Do not use this product for any purpose that is not explicitly specified in this
manual. Do not exceed weight capacity. We are not liable for damage or
injury caused by improper mounting, incorrect assembly or inappropriate use.
Minimum VESA pattern:75mm/3 in.(W)x75mm/3 in.(H)
If your TV VESA is greater than 100x100 mm/4x4 in. or less than
VESA 75x75mm/3x3in., this mount is NOT compatible.
If this mount is NOT compatible, please contact customer service at
support@huanuoav.com to find a compatible mount.
Monitor Plate
Support Pillar Cable Clip Knob Grommet Plate
X1
06
X1
07
Monitor Connector Base
Tools Required [Not Included]
Drill(Optional)
To Next Page
