Huawei AP4030DN
Hardware Installation and Maintenance Guide
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Before fixing the adjustable buckle with a screw, you need to adjust the buckle to a proper position
based on the T-rail width.
Ensure that the AP is correctly installed on the mounting bracket and there must be 200 mm space
above and around the AP for maintenance.
2.6 Connecting Cables
Figure 2-3 show the appearance of AP4030DN.
Figure 2-3 Appearance of AP4030DN
Table 2-2 Cable connections
