1 AP Overview
1.1 Device Structure
Figure 1-1 show the appearance of AP4030DN
Figure 1-1 Appearance of AP4030DN
Table 1-1 describes interfaces on AP4030DN.
Table 1-1 Interfaces on AP4030DN
No.
Name
Description
1
GE/PoE
10/100/1000M bit/s
interface: connects to the
wired Ethernet. The
interface can connect to a
PoE power supply to
provide power for the AP.
2
DC 12V
DC power socket: connects
