1 Introduction to PAA
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5
1.3.2 Accessory List
Table 1-4 lists the accessories of APAA00001.
Table 1-4 Accessories of APAA00001
No.
Accessory
Quantity
1
12 V DC adapter
1 PCS
2
AC power cable
1 PCS
3
AISG 1-to-2 cable
1 PCS
4
N(M)-DIN(M) adapter
1 PCS
5
N(M)-DIN(F) adapter
1 PCS
6
RF cable
1 PCS
7
Strap
1 PCS
8
User manual
1 PCS
12 V DC Adapter
The adapter parameters are as follows:

Input: 100 V AC to 240 V AC, 0.8 A, 50 Hz to 60 Hz

Output: 12 V DC, 2.0 A AC/DC
Figure 1-3 shows the 12 V DC adapter.
Figure 1-3 12 V DC adapter
AISG 1-to-2 Cable
The cable specifications are as follows:

Connectors: Each AISG 1-to-2 cable has three 8-core connectors that comply with the
IEC 60130-9 standard: one female connector and two male connectors.
