Item Specification
EMMC flash
memory
4 GB
Micro SD card
(default: sd1)
None
Hard disk Supported
Dimensions and weight
Dimensions (W x
D x H)
275.0 mm x 160.0 mm x 30.0 mm (10.8 in. x 6.3 in. x 1.2 in.)
Weight 1.3 kg (2.87 lb)
Power specifications
Rated input voltage
(DC)
12 V/24 V
NOTE
The router has two power terminals for DC power supply and supports power
supply control using a power key.
Maximum input
voltage (DC)
8 V DC to 36 V DC
Maximum output
current
4 A
RPS power supply Not supported
PoE power supply Not supported
Power consumption
Maximum power
consumption
25 W
Heat dissipation
Fans None
Airflow (facing the
front panel)
None
Interface density
Management
interfaces
None
Console interfaces 1 (Micro USB)
USB 2.0 interfaces 1
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description
7 Technical Specifications
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
108
