Huawei AR500 - Ar531-F2 C-H

Item Description
Part number 50010172
7.3.2 AR531-F2C-H
Technical Specifications
Table 7-20 lists technical specifications of the AR531-F2C-H router.
Table 7-20 AR531-F2C-H technical specifications
Item
Specification
System parameters
Processor Dual-core, 533 MHz
Memory 512 MB
Flash 512 MB
Dimensions and weight
Dimensions (W x D x H) 220 mm x 250 mm x 88 mm (8.7 in. x 9.8
in. x 3.5 in.)
Weight ≤ 5 kg (11.0 lb)
Power consumption
Maximum power consumption 21 W
Power specifications
AC power input
l Rated voltage range: 100 V to 240 V
(single-phase) or 345 V to 415 V (three-
phase)
l Maximum voltage range: 90 V to 290 V
(single-phase) or 304 V to 456 V (three-
phase)
Interface density
Console interfaces 2
USB 2.0 interfaces 1
RS485 interfaces 2
DI interface 2
