Figure 4-10 AR509CG-Lt appearance
Config
GE1MGMT
GE0
GE3
AR509CG-Lt
6
5
3 4
12
7
1
CON RS232
GE2
Removing the SIM card cover from the bottom:
Interfaces on the router:
8
1
LTE antenna interface 2 Ground point
NOTE
Reliably ground the router by connecting a
ground cable to the ground point to protect
the router against lightning and interference.
3 USB interface (host) 4 CON/RS232 interface
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description
4 Appearance
