Table 7-4 AR503GW-LM7 technical specifications
Item Specification
System parameters
Processor Dual-core, 1 GHz
Memory 1 GB
Flash memory 256 MB
Micro SD card
(default: sd1)
None
Hard disk mSATA hard disk supported
Dimensions and weight
Dimensions (W x
D x H)
200 mm x 160 mm x 44 mm (7.87 in. x 6.30 in. x 1.73 in.)
Weight 1.4 kg (3.09 lb)
Power specifications
Rated input voltage
(DC)
12 V/24 V
Maximum input
voltage (DC)
8 V to 36 V
Maximum output
current
3 A
RPS power supply Not supported
PoE power supply Not supported
Power consumption
Maximum power
consumption
13 W
Heat dissipation
Fans None
Airflow (facing the
front panel)
None
Interface density
Management
interfaces
None
RS232 interfaces 1 (DB9)
USB 2.0 interfaces 1
