Huawei DTSU666-HW User Manual

10
The button → is used to switch the displays. Set parameter disp to enable the rotation
display function.
4
Display and Parameter Settings
No. Display Description No. Display Description
1
Positive active
energy
= 10000.00 kWh
2
Negative active
energy
= 2345.67 kWh
3
None parity,
8 data bits,
and 1 stop bit;
baud rate
= 9600
bps (default)
4
011 represents
address
(default)
5
Phase A voltage
= 220.0 V
6
Phase B
voltage
= 220.1 V
7
Phase C voltage
= 220.2 V
8
Phase A
current
= 5.000 A
9
Phase B current
= 5.001 A
10
Phase C
current
= 5.002 A
11
Total phase active
power = 3.291
kW
12
Phase A active
power = 1.090
kW
13
Phase B active
power = 1.101
kW
14
Phase C active
power
= 1.100 kW
15
Total phase
power factor
PFt = 0.500
16
Phase A power
factor
PFa = 1.000
17
Phase B power
factor
PFb = 0.500
18
Phase C power
factor
PFc = –0.500
Display
4.1
