Huawei E5172 User Manual

3
UK
 Off: The device is powered off.
○
2
WLAN indicator
 On: WLAN function enabled
 Blinking: Transmitting data through WLAN
 Off: WLAN function disabled
○
3
WPS indicator
 On: WPS function enabled
 Blinking: WPS interconnection verification is in progress. This process should not
take longer than 2 minutes.
 Off: WPS function disabled
○
4
LAN indicator
 On: The port is connected to a device.
 Blinking: Data is being transmitted through the port.
 Off: No device is connected to the port.
○
5
Voice indicator
 On: Off-hook condition
 Blinking: Incoming call
 Off: On-hook condition
○
6
Signal indicator
 On: Indicates network signal strength. Full light indicates strong signal.
 Off: No network signal.
○
7
WLAN button
Press and hold for more than 2 seconds to enable or disable the WLAN function.
○
8
Reset button
Press and hold for more than 2 seconds to restore the device to its factory settings.

Huawei E5172 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	1
DHCP client	-
Security algorithms	WEP, WPA, WPA2
4G standard	LTE
2G standards	EDGE, GPRS, GSM
3G standards	HSDPA, HSPA+, HSUPA

Weight and Dimensions

Depth	32 mm
Width	173 mm
Height	124 mm
Weight	500 g
