18
7 Appendix
7.1
Indicators
Indicator Status Description
Solid on The HG531 is powered on. POWER
Off The HG531 is powered off.
Blinking The HG531 is being activated.
Solid on The HG531 is activated.
ADSL
Off The HG531 is powered off.
Blinking z The HG531 works in routing mode.
z The WAN connection is set up.
z Data is being transmitted.
Solid on z The HG531 works in routing mode.
z The WAN connection is set up.
z No data is being transmitted.
INTERNET
Off
z The HG531 works in bridge mode or in routing
mode.
z No WAN connection is set up.
Blinking z The wireless network function is enabled.
z Data is being transmitted through the WLAN.
Solid on z The wireless network function is enabled.
z No data is being transmitted through the WLAN.
WLAN
Off The wireless network function is disabled.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Huawei EchoLife HG531 and is the answer not in the manual?

Huawei EchoLife HG531 Specifications

General IconGeneral
ModelHG531
CategoryGateway
Wireless Standard802.11b/g/n
Frequency Band2.4 GHz
Ethernet Ports4 x 10/100 Mbps
USB PortNo
WirelessYes
Operating Temperature0°C to 40°C
Storage Temperature-40°C to 70°C
Power Supply12V DC, 1A
ADSL StandardITU G.992.1 (G.dmt), ITU-T G.992.2 (G.lite), ITU-T G.992.3 (ADSL2), ITU-T G.992.5 (ADSL2+)
SecurityWEP, WPA, WPA2
Ports4 Ethernet, 1 DSL
Operating Humidity5% to 90% (non-condensing)
WLAN SpeedUp to 54 Mbps (802.11g), Up to 150 Mbps (802.11n)
