Huawei EchoLife HG531 User Manual

19
Indicator Status Description
Blinking
This indicator has three blinking modes that indicate
three states.
z The indicator periodically blinks and is on for 0.2s
and off for 0.1s, which indicates that the WPS
function is activated and that a wireless terminal
can connect to the HG531.
z The indicator periodically blinks and is on for 0.1s
and off for 0.1s, which indicates that a wireless
terminal fails to connect to the HG531.
z The indicator is on for 0.1s and then off for 0.1s.
After this process repeats for four times, the
indicator is off for 0.5s. Then, the indicator blinks
as the preceding process, which indicates a wireless
terminal is setting up a connection to the HG531.
Solid on
A wireless terminal is connected to the HG531
through the WPS protocol. This state lasts 300s.
WPS
Off
The HG531 does not perform the WPS negotiating
operation, or the WPS functional module is faulty.
Blinking
Data is being transmitted through the Ethernet
interface.
Solid on The Ethernet connection is set up.
LAN1–LAN4
Off The Ethernet connection is not set up.
Blinking Data is being transmitted on the USB port.
Solid on The USB port is connected.
USB
Off The USB port is not connected.
7.2
Interfaces and Buttons
Interface or
Button
Description
POWER It is used to connect the power adapter.
USB It is used to connect the USB storage device.
LAN1–LAN4 It is used to connect to the Ethernet interface on the computer.

Huawei EchoLife HG531 Specifications

General

Model	HG531
Category	Gateway
Wireless Standard	802.11b/g/n
Frequency Band	2.4 GHz
Ethernet Ports	4 x 10/100 Mbps
USB Port	No
Wireless	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Power Supply	12V DC, 1A
ADSL Standard	ITU G.992.1 (G.dmt), ITU-T G.992.2 (G.lite), ITU-T G.992.3 (ADSL2), ITU-T G.992.5 (ADSL2+)
Security	WEP, WPA, WPA2
Ports	4 Ethernet, 1 DSL
Operating Humidity	5% to 90% (non-condensing)
WLAN Speed	Up to 54 Mbps (802.11g), Up to 150 Mbps (802.11n)
