Traffic statistics: TCP,UDP,RTP
VoIP call statistics
PSTN call statistics: ASR,ACD,PDD
System log outputs CDR and tracing information
Web-based Ping and Tracer tests
Transmission protocol statistics: TCP, UDP, RTP
VoIP call statistics
PSTN call statistics: ASR,ACD,PDD
Physical
properties
Power: input:100-240V,50-60Hz,1.1A Max, output:12VDC,4.0A
Power consumption:4G: 15w; 8G: 25w
Temperature (operation): 0 ℃ to +45 ℃
(storage): -20 ℃ to +80 ℃
Operation Humidity: 10%-90% no condensation
Dimensions (W/D/H): 255 mm x 220 mm x 30 mm
Weight: 1.48 kg
Color & material: blue, aluminum box
Packing content
Gateway
RJ-45 network cable
Antenna
User's manual CD
7.3 PSTN Gateway
The Huawei PSTN gateway U1911 is used. For details, see eSpace U1911 Unified Gateway
V100R001C20 Product Overview.
7.4 TETRA Gateway
TETRA gateways support the PTT signaling, AT commands, VOX, COR (carrier detect),
channel change, PTT hotline, and rich specifications, applicable to various application
scenarios and network sizes.
7.4.1 TETRA Gateway Structure
TETRA Gateway
Description
ETS-2WP
Trunking, ultra short wave, and short wave gateway, providing VOX
and COR, and supporting two channels
ETS-4WP
Trunking, ultra short wave, and short wave gateway, providing VOX
and COR, and supporting four channels
