Cable Layout Effect of the Chassis
•Connect the cables of the same type to the interfaces on the chassis in a
sequence from left to right.
•Routing cables upward is recommended.
•The preceding figure shows the cable layout effect of the NE05E-SI and
NE08E-S6 equipment installed in a 19-inch cabinet. It is for reference
only.
AC Equipment:
DC Equipment:
NOTE
