a. Configure the access switch.
Starting with access switch ACC1 as an example, create service VLAN 10 on ACC1.
1
<HUAWEI> system-view
[HUAWEI] sysname ACC1 //Set the switch name to ACC1.
[ACC1] vlan batch 10 //Create VLANs in a batch.
Configure Eth-Trunk 1, through which ACC1 connects to the CORE, to allow the
packets from the VLAN of department A to pass through.
2
[ACC1] interface eth-trunk 1
[ACC1-Eth-Trunk1] port link-type trunk //Set Eth-Trunk 1 type to
Trunk for VLAN transparent transmission.
[ACC1-Eth-Trunk1] port trunk allow-pass vlan 10 //Configure Eth-Trunk 1
to transparently transmit the service VLAN on ACC1.
[ACC1-Eth-Trunk1] mode lacp //Configure the LACP mode
on Eth-Trunk 1.
[ACC1-Eth-Trunk1] quit
[ACC1] interface GigabitEthernet 0/0/1 //Add member interfaces to
Eth-Trunk 1.
[ACC1-GigabitEthernet0/0/1] Eth-Trunk 1
[ACC1-GigabitEthernet0/0/1] quit
[ACC1] interface GigabitEthernet 0/0/2
[ACC1-GigabitEthernet0/0/2] Eth-Trunk 1
[ACC1-GigabitEthernet0/0/2] quit
9
Configuring Interfaces and VLANs
