Mid-sized Campus WLANs
55
A WLAN with SSID wlan-net is required so that users can access the Internet from
anywhere at any time.
The S5720LI that supports the PoE function can be deployed at the access layer
and connects to APs to provide wireless network access for STAs.
The S5720HI can be deployed as an AC at the aggregation layer to control and
manage STAs. The AC functions as a DHCP server to assign IP addresses to APs.
An AR series router can be deployed as the egress of the campus network. The
router functions as a DHCP server to assign IP addresses to STAs.
VLANs in a VLAN pool can be configured as service VLANs. IP addresses are
assigned to STAs from the interface address pools corresponding to the VLANs in
the VLAN pool.
This section uses an S series switch running V200R012 and an AR
series router running V200R010 as examples to demonstrate how to
configure a medium-sized campus WLAN.
.
