Console port
The console port is connected to a console for on-site conguration. Table 5-51
describes the attributes of the console port.
Table 5-51 Attributes of the console port
Attribute Description
Connector type RJ45
Standards
compliance
RS-232
Working mode Duplex Universal Asynchronous Receiver/Transmitter (UART)
Baud rate 9600 bit/s, 19200 bit/s, 38400 bit/s, 57600 bit/s, or 115200
bit/s
Default value: 9600 bit/s
ETH management port
You can connect a switch to a
conguration terminal or network management
workstation through the ETH management port to congure the switch locally or
remotely. Table 5-52 describes the attributes of an ETH management port. You
can log in to the switch that contains the ETH management port for the rst time
through the ETH management port. For details, see "First Login to a Switch" in
the Conguration Guide - Basic Conguration . If you have logged in to the switch
for the rst time by pressing and holding the MODE button for 6 seconds or
longer and saved the conguration, the default conguration on the ETH
management port will be cleared. In this case, you cannot log in to the switch for
the rst time through the ETH management port. You are advised to log in to the
switch for the rst time through the ETH management port.
Table 5-52 Attributes of an ETH management port
Attribute Description
Connector type RJ45
Standards
compliance
IEEE802.3
Working mode 10/100 Mbit/s auto-sensing
Maximum
transmission
distance
100 m
USB port
S1700 Managed Series Ethernet Switches
Product Description
5 Hardware Structure
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 140
