A 10/100/1000BASE-T Ethernet electrical port sends and receives service data at
10/100/1000 Mbit/s. Table 5-56 describes the attributes of a 10/100/1000BASE-T
Ethernet electrical port.
Table 5-56 Attributes of a 10/100/1000BASE-T Ethernet electrical port
Attribute Description
Connector type RJ45
Standards
compliance
IEEE802.3, IEEE802.3u, IEEE802.3ab
Working mode 10/100/1000 Mbit/s auto-sensing
Maximum
transmission
distance
100 m
1000BASE-X port
When a 1000BASE-X port uses a GE optical module, it can only transmit and
receive data at 1000 Mbit/s and does not support the 100 Mbit/s transmission
speed. When a 1000BASE-X port uses a GE copper module, it can transmit and
receive data at 10 Mbit/s, 100 Mbit/s, or 1000 Mbit/s. Table 5-57 describes the
attributes of a 1000BASE-X port.
Table 5-57 Attributes of a 1000BASE-X port
Attribute Description
Connector type LC/PC
Optical port
attributes
Depend on the module used
Standards
compliance
IEEE802.3z
Console port
The console port is connected to a console for on-site
conguration. Table 5-58
describes the attributes of the console port.
Table 5-58 Attributes of the console port
Attribute Description
Connector type RJ45
Standards
compliance
RS-232
S1700 Managed Series Ethernet Switches
Product Description
5 Hardware Structure
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 149
